SPECIFICATIONS:
GENERATOR
Rated frequency (Hz): 60
Rated voltage (V): 220
Maximum output (kVA): 5.2
Rated rotation speed (rpm): 3600
DC output: 12V7A
Power factor cos Ø: 1
Phase number: Single Phase
Excitation mode: Self-excitation Brush type
Noise level dB (A)/7m
(zero load~full load): 70~74
Overall dimensions [mm(in)] (LxWxH): 970 x 580 x 785(3819 x 22.83 x 30.91)
Dry weight [Kg(lbs)]: 186(409.20)
Structure model: Silent
Connection mode: Single bearing rotor drive shaft rigid coupling
ENGINE
Engine model: PM186FAE
Engine type: Single cylinder, 4-stroke, air-cooled, vertical, diesel engine
Displacement (cc): 418
Compression ratio: 19:1
Maximum output (HP): 12
Starting system: Dual Start (ELECTRIC & MANUAL)
Lube brand: SAE40
Low oil pressure alarm: With
