FEATURES
Super mechanical strength and excellent abrasive resistance.
Superior heat and cold resistance.
Oil resistance.
Light weight.
Could accept custom-made.
(Packing, or Length and can connect with different fitting or coupler.)
SPECIFICATIONS
| PART NO. | I.D (mm) | O.D(mm) | Length | Temperature | Working Pressure at 23°C (73.4 °F) |
| HUS2504 | 2.5 | 4 | 200M | -20°C~60°C (-5°F ~+140°F) | 150PSI (1MPa) |
| HUS0406 | 4 | 6 | 200M |
| HUS0508 | 5 | 8 | 100M |
| HUS6510 | 6.5 | 10 | 100M |
| HUS0812 | 8 | 12 | 100M | 135PSI (0.9MPa) |
| HUS1014 | 10 | 14 | 50M | 100PSI (0.67MPa) |
| HUS1216 | 12 | 16 | 50M |
| HUS95135 | 9.5 | 13.5 | 50M |
NOTE:Colors Available
Green(GN), Yellow(YE), Orange(OR), Blue(BS), Black(BK), Red(RD), Clear(CL)
