FEATURES:
- The design allows straight edges, contours, and cutouts to be beveled with ease
- Works with steel, stainless steel, aluminum, copper, plastic and other materials
- The precision dial scale allows precise adjustment of the chamfer height
- The precision dial scale allows precise adjustment of the chamfer height
- Variable electronic speed control allows stable cutting speed, no matter the load, for precision results with various materials
- Optional tool holders with different bevel angles available
SPECIFICATIONS:
| Model |
EB12 |
| Power Input |
1800W |
| Voltage |
220V~60Hz |
| No Load Min-1 |
2300 - 6500 |
| Speed Wheel Settings |
1/ 2/ 3/ 4/ 5/ 6: 2300/ 2600/ 3700/ 4800/ 5800/ 6500 |
| Std. Bevel Angle |
45 Deg. |
| Max. Chamfer Height |
45 Deg. : 10.6 mm |
| Mini. Dia. For Inside Bevels |
30mm |
| Soft Start & Overload Protection |
With |
| Dimensions(LxWxH) |
485mm x 192mm x 150mm |
| Net Weight |
6.35kg(14Lbs) |
Standard Accessories: 45 Deg. Tool Holder Set, Square Carbide Inserts 6pcs. Torx Wrench T15, HEx Wrench m6, Hook Spanner Wrench, Spindle Lock Bar
