FEATURES:
- Pump unit is made with precision mould aluminum, durable cast-iron volute, semi open cast-iron implier, mechanical seal.
SPECIFICATIONS:| Model | SCR-50HG | SCR-80HG |
| Pump Type | OEL-50 | OEL-80 |
| Inlet ø x Outlet ø mm (inch) | 50 x 50 (2x2) | 80 x 80 (3x3) |
| Max. Total Head m(ft) | 32 (105) |
| Sunction Lift m(ft) | 33 (105) |
| Priming Water Capacity (l) | 2.1 | 3.8 |
| Max Capacity (l/min) | 520 | 1000 |
| Max Shutoff Pressure (Mpa) | 0.3 |
| Engine Maker | HG |
| Engine Model | HG170P |
| Displacement (cm3) | 163 |
| Max Power KW(PS)/4000min-1 | 4.0 (5.4) |
| Fuel | Automobile Gasoline |
| Fuel Tank Capacity | 3.3 |
| Starting System | Recoil |
| Dry Weight | 25 | 26 |
| Packing Measurement LxWxH | 543 x 384 x 447mm |
