KOBEWEL MULTI-PROCESS INVERTER WELDER, Xi 200PM
Product Description (英文):
The KOBEWEL Xi 200PM is a premier Multi-Process Inverter Welder engineered to deliver outstanding welding versatility and powerful performance for professional and industrial applications. With advanced inverter technology, this welder guarantees high efficiency, easy operation, and reliable results for MIG, FCAW, Stick/MMA, and TIG welding processes.
Key Specifications:
- Welding Current Range: 30 – 200 A, offering precise control for various welding tasks.
- Load Voltage: 15.5 – 24.0 V ensures consistent and stable arc performance.
- Input Power: 7.4 KVA single phase (1 Ph), compatible with 220 V power (±15% tolerance), 50/60 Hz.
- Duty Cycle: 40% @ 40°C, designed for demanding environments.
- Open Circuit Voltage: High 66 V for easy arc starting.
- Efficiency: High at 0.85, reducing energy consumption.
- Power Factor: 0.76 for optimal energy efficiency.
- Index Protection: IP 21S, offers protection against solid objects and drips.
- Insulation Class: B, ensuring electrical safety in operation.
- Cooling Type: F, robust cooling for continuous use.
- Wire Compatibility:
- Aluminum: 1.0 – 1.2 mm
- Flux-cored: 1.0 mm
- Steel: 0.8 – 1.0 mm
- Spool Wire Max Capacity: 5 kg, suitable for extended welding sessions.
- Dimensions (L x W x H): 420 x 190 x 250 mm.
- Weight: 14 kg, providing portability and compactness.
Complete Kit Includes:
- Ground clamp with welding cable
- Air hose with 2 pcs hose clamps
- Welding Helmet 35F-KDH
- CO2 Regulator with Heater KR-12CO
- Air-cooled (24KD) MIG Torch, 3M
- Extra Teflon Liner (1.0 – 1.2 mm²)
- 1 pc Coupler Socket Hose 20SF
- 1 pc Cable Connector 35–50 mm²
- Drive Roller V-Groove (0.8 & 1.0), Knurled Groove (0.8 & 1.0), U-Groove (1.0 & 1.2)
- 3 pcs Contact TIP
- Optional: MIG Spool Gun KL-SG01
Standard Accessories:
- Air-cooled MIG Torch, 3 m length
- Ground clamp with welding cable
- Air hose with 3 pcs hose clamps
- Welding Helmet 10F-KDH
Multi-Process Functionality:
- MIG / FCAW: Air-cooled MIG torch (3M), CO2 regulator with heater (KR-12CO)
- Stick/MMA: Euro type quick connector (35–50 mm²), Electrode Holder KEH-300A, 2 m welding cable 35 mm²
- TIG: Air-cooled TIG torch KL-25009, Thoriated Tungsten Electrode 1.6 mm, Argon Regulator KR-10AR
Expert Summary: The KOBEWEL Xi 200PM sets a new standard in welding equipment, combining robust construction, user-friendly controls, and unmatched multi-process flexibility. With comprehensive accessories and versatile welding capabilities, this machine is an ideal choice for professionals who demand top-tier performance, efficiency, and reliability on every project. From aluminum and steel to flux-cored applications, the Xi 200PM delivers superior arc quality and all-in-one convenience—perfect for workshops, factories, and experienced welders alike.
