FEATURES:
- Revolutionary compact slide system allows the saw head to slide along fixed rails, eliminating the need for rear clearance
- Exclusive laser marker system from Hitachi increases cutting accuracy
- Micro miter and micro bevel adjustment knobs to dial-in to precise angles
- Large pivoting fence raises fence height to 4-11/16 inches to cut crown molding vertically
- 0-57 degree miter angle to the right for flexibility with 0-46 degree miter angle to the left
- 0-45 bevel angle range to the right and left allowing users to quickly and easily flip the saw blade and leave the material in place
- Positive stops on the miter and bevel scale, for easy to read measurements and quick settings
- Carbon brush access, allows the user to replace the brush as needed to greatly prolong tool life
- Vertical handle with soft, vibration reducing elastomer grip adds comfort and control
SPECIFICATIONS:
Capacity: Blade Diameter 305mm (12")
(H x W) Cross Cut: 0 107x312mm (4-3/16 x 12-1/4:)
Compound: Milter 45° Left 70 x 220mm (2-3/4 x 8-21/32")
Bevel 45° Left See below detail.
Power Input 1,600W
No load Speed 3,800/min
Milter Angle: Right: 0-57° Left: 0-46°
Bevel Angle: Right: 0-45° Left: 0-45°
Positive Miter Angle Stop 0,15,22.5 and 45 0
Dimensions 595 x 990 x 710mm
Weight 29kg (63.9 lbs.)
Standard Accessories Blade, Dust bag, Vise Ass'y, Box Wrench
