FEATURES:
- A high-precision wet tile saw which uses continuous rim diamond blades only
- The unique water circulation design minimizes water loss and spillage while the water tray is easy to mount and refill.
- The dimensionally stable table allows accurate cutting and the parallel cutting guide with the angle guide plate allow precise guidance of the workpiece.
- The sturdy motor mount system allows the motor to tilt up to 45 degrees for accurate miter cuts.
- The AC induction motor operates at a very stable speed, is quiet, water-resistant and long-lasting.
SPECIFICATIONS:
| Model | TS9 |
|---|
| Motor Type | Single Phase AC Induction |
|---|
| Power Output | 800W |
|---|
| Voltage | 110-120V~ 50-60Hz, 220-240V~ 50-60Hz |
|---|
| No Load/Min-1 | 3000 (50Hz), 3600 (60Hz) |
|---|
| Max. Blade Diameter | 230mm (9") |
|---|
| Blade Bore | 25.4mm (1") |
|---|
| Bevel Capability | 0-45 deg. |
|---|
| Max. Cutting Depth-Straight | 48mm (1-7/8") |
|---|
| Max. Cutting Depth- At 45 Deg. | 37mm (1-7/16") |
|---|
| Table Cutting Width -Left | 305mm (12") |
|---|
| Table Cutting Width -Right | 147mm (5-3/4") |
|---|
| Protection | IP44 |
|---|
| Dimensions(LxWxH) | 660mm x 595mm x 320mm |
|---|
| Net Weight | 14.7kg (32.41 Lbs) |
|---|
Standard Accessories: Diamond Blade, Parallel Cutting Guide, Angle Guide Plate,
M8 Combination Wrench, m19 Combination Wrench
